Electrical design and PLC control panels
A control panel is only as good as its drawings. We start with the electrical design: power distribution, motor circuits, safety circuits and the full I/O list. Then we assemble, wire and label the panel and test it before it reaches your site.
What our control-panel work covers
We build panels for new machines, for upgrades of existing machines and for process equipment. Components are chosen for your budget and for spare parts you can buy in Egypt.
Electrical design
Schematic drawings of power and control circuits in EPLAN Electric P8, panel layouts, cable lists and the full I/O list.
PLC and motor-control panels
PLC, HMI, VFDs, contactors, overload relays, circuit breakers, relays and terminals in one enclosure, sized for your machine.
Wiring and labeling
Wiring in cable ducts, ferrules and wire numbers, and labeled devices and terminals that match the drawings.
Safety circuits
Emergency-stop and door circuits, phase monitoring and interlocks, designed into both the wiring and the control logic.
Testing before delivery
Wiring checks, power-up tests and I/O simulation with the PLC program before the panel leaves for site.
Design practice
Panels designed following IEC 60204-1 (electrical equipment of machines) and IEC 61439 (low-voltage assemblies) practice.
Projects
Panels we have built
Siemens S7-1200 PLC
Syrup jet mixing system on Siemens S7-1200 and SIMATIC HMI
Delta DVP-12SC PLC
Four-nozzle shampoo filler with Delta PLC and Arabic HMI
When you need a new control panel
- A new machine needs its control panel
- An old relay panel should be replaced with a PLC
- A panel has no drawings and needs documenting
- An imported machine needs a local panel or changes to its panel
What you receive
- Schematic drawings (EPLAN Electric P8) and panel layout
- I/O list and bill of materials
- Assembled, wired and labeled panel
- Completed pre-delivery test checklist
- As-built drawings after commissioning
